T3 27

T3-27
1) T3 27
2) T3 27 MAG (PM-100)
Product Number:
2207015.01 T3 27
Included:
Hole mount: N Chrome (P/N:2500102.01)
Cable: 4m/13ft Cable for N or N-PL mounts (P/N:2505705.00)
Screw Bolt
2207015.61 T3 27 MAG (PM-100)
Included:
Magnetic Mount: PM-100 S (P/N:2502502.01)
Screw Bolt
2207015.63 SUPER T3 27 MAG (PM-125)
Included:
Magnetic Mount: PM-125 S (P/N:2502602.01)
Screw Bolt
Electrical Data:
Type: Logarithmic loaded
Radiation: Omnidirectional
Polarization: Linear vertical
Frequency range: 26.9 … 27.5 MHz Tunable
Systems: CB 27MHz
Bandwidth: ≥ 700KHz @ SWR ≤ 2
Max Power: 20 Watts (CW) continuous
100 Watts (CW) short time
Cable lenght / type:
T3 27:
4 m (13.12 ft) / RG58
T3 27 MAG (PM-100):
3.6 m (11.81 ft) / RG58
SUPER T3 27 MAG (PM-125):
3.6 m (11.81 ft) / RG58
Connector:
T3 27:
Not supplied
T3 27 MAG (PM-100):
UHF-male (PL-259)
SUPER T3 27 MAG (PM-125):
UHF-male (PL-259)
Mechanical Data:
Materials: Brass, Stainless steel, Nylon
Height (approx): 620 mm / 2.03 ft
Weight (approx): 400 gr / 0.88 lb
Mounting type:
T3 27:
Thru-Hole
T3 27 MAG (PM-100):
Magnetic mount
SUPER T3 27 MAG (PM-125):
Magnetic mount
Suitable Accessories:
Hole mount: NE Chrome (P/N:2500202.01)
Bracket: ABN-2 Trunk Mount (P/N:2504105.00)
Bracket: KF Gutter mount (P/N:2504205.00)
Bracket: Asp-1 Chrome (P/N:2504004.00)
Connector: UHF-male (PL-259) (P/N: 2505600.00)
