Product Number:
2115020/118	SPO-118-2

Electrical Data:
Type:	1/2 λ
Radiation:	Omnidirectional
Polarization:	Linear vertical
Frequency range:	TX band: 118-136 MHz @ SWR ≤1.5 No tuning required RX band: 108-136 MHz
Systems:	VHF Airband
Gain:	0 dBd – 2.15 dBi
Max Power:	100 W (CW)
Grounding protection:	DC-Ground
Connector:	N-female

Mechanical Data:
Materials:	Anodized Aluminium, Brass, Stainless steel, Fiberglass, EPDM rubber
Height (approx):	1700 mm / 5.58 ft
Weight (approx):	1400 gr / 3.09 lb
Mounting type:	On-Mast
