Features:
Now available with new MAG-60-S magnetic mount

Product Number:
2205905.32	MGA 55-550 SL Included: Hole mount: SL Wing Bolt
2205905.28	MGA 55-550 S Included: Hole mount: S Screw Bolt
2213805.32	MGA 108-550 SL Included: Hole mount: SL Wing Bolt
2213805.28	MGA 108-550 S Included: Hole mount: S Screw Bolt
2213805.72DV	MGA 108-550 MAG-60-S Included: Screw Bolt

Electrical Data:
Type:	1/4 λ
Radiation:	Omnidirectional
Polarization:	Linear vertical
Frequency range:	MGA 55-550 SL: 55 … 550 MHz Tunable MGA 55-550 S: 55 … 300 MHz Tunable MGA 108-550 SL: 108 … 550 MHz Tunable MGA 108-550 S: 108 … 300 MHz Tunable MGA 108-550 MAG-60-S: 108 … 550 MHz Tunable
Systems:	2m-HAM, 1.25m-HAM, 70cm-HAM, VHF Airband, VHF Marine Band, VHF Low-band (66-88MHz), ORBCOMM M2M, AIS-162MHz, TETRA-350, TETRA, CDMA-450, LTE-450, FM, ISM-169MHz, VHF-260MHz
Gain:	0 dB ref. to a λ/4 whip
Max Power:	100 W (CW)
Cable lenght / type:	MGA 55-550 SL: 5 m (16.4 ft) / RG58 MGA 55-550 S: 5 m (16.4 ft) / RG58 MGA 108-550 SL: 5 m (16.4 ft) / RG58 MGA 108-550 S: 5 m (16.4 ft) / RG58 MGA 108-550 MAG-60-S: 3 m (9.84 ft) / RG58
Connector:	MGA 55-550 SL: Not supplied MGA 55-550 S: Not supplied MGA 108-550 SL: Not supplied MGA 108-550 S: Not supplied MGA 108-550 MAG-60-S: UHF-male (PL-259)

Mechanical Data:
Materials:	Chromed brass, Stainless Steel 17/7 PH, Nylon
Height (approx):	MGA 55-550 SL: 1400 mm / 4.59 ft MGA 55-550 S: 1400 mm / 4.59 ft MGA 108-550 SL: 705 mm / 2.31 ft MGA 108-550 S: 705 mm / 2.31 ft MGA 108-550 MAG-60-S: 740 mm / 2.43 ft
Weight (approx):	MGA 55-550 SL: 420 gr / 0.93 lb MGA 55-550 S: 420 gr / 0.93 lb MGA 108-550 SL: 420 gr / 0.93 lb MGA 108-550 S: 420 gr / 0.93 lb MGA 108-550 MAG-60-S: 500 gr / 1.1 lb
Mounting type:	MGA 55-550 SL: Thru-Hole MGA 55-550 S: Thru-Hole MGA 108-550 SL: Thru-Hole MGA 108-550 S: Thru-Hole MGA 108-550 MAG-60-S: Magnetic mount

Suitable Accessories:
Hole mount: N Chrome (P/N:2500102.01)
Magnetic Mount: PM-125 S (P/N:2502602.01)
